en-24
5 CONTROLS
5.2.K AUXILIARY HYDRAULIC SERVICES KIT SWITCH (OPTIONAL) ______________
Used to slew the rotary brush or snow blade to the right or to the left.
Push the front of the rocker switch to slew to the right.
Push the rear of the rocker switch to slew to the left.
5.2.L LIGHT SWITCH (OPTIONAL)___________________________________________
Allows manual operation of the road lights.
Position 1. OFF
Position 2. Side / Marker Lights
Position 3. Dipped Beam.
Note, Position 3 needs the ignition in the ON position.
5.2.M HAZARD WARNING SWITCH (OPTIONAL) _______________________________
Turns the four indicator lamps ON.
Push the front of the switch to turn ON
Push the rear of the switch to turn OFF
When the switch is turned on, the red lens flashes.
5.2.N ROTATING BEACON (OPTIONAL) ______________________________________
Operates the vehicles rotating beacon when a cab is not fitted.
