Ransomes HM600 - Anguage Menu; Anguage Option

en-42
5 CONTROLS
5.2.Z.55 LANGUAGE MENU ______________________________________________
Select the language  and accept
5.2.Z.56 LANGUAGE OPTION ____________________________________________
On the page for the language options, Press the button to select, press the
button up and down to move the . When the  is moved up and down
the languages, it does not change until button is pressed to store the
language. When the title bar, i.e. the 'Language Menu' will change to the new
language.
The options will be in the correct language i.e. English, Deutsch, Francais,
Dansk, Svensk, Nederlands and Español.
Press the button to return to previous menu.
WARNINGS
5.2.Z.57 WARNING OIL-PRESSURE FAULT ____________________________________
When this screen is shown, the engine oil pressure has decreased below the
normal
level. If this happens during operation, Stop the engine and check the oil level.
Top up if necessary. If the problem persists consult your service dealer.
Press the button below the  to confirm the fault.
5.2.Z.58 WARNING SLOPE ANGLE - INHIBIT LIFT ______________________________
If the slope angle reaches the warning value the screen will display this warning
which indicates that the cutting unit arms are locked in the current position and
will continue to run but cannot be re engaged. An audible warning will be
sounded, the warning will sound four times every 4 seconds and the red LED’s
will flash four times every 4 seconds. This will continue until the machine has
been driven to an area with a slope less than the warning value.
Angle values - Inhibit lift;
HM600 with ROPS 20 deg
HM600 with Cab 19 deg
Press the button below the
 to confirm the fault.
0°
Slopes > = 19°
in either x or y

0°
Slopes > = 16°
in either x or y
Language
English

Deutsch
Francais
Dansk
Svensk
Netherlands
Espanol
Main Menu
Clock
Service
Settings

Language
