5 CONTROLS
5.2.Z.59 WARNING SLOPE ANGLE - INHIBIT CUT ______________________________
If the slope angle reaches the value for inhibit cut the screen will display this
warning
indicating that the front cutter deck will be lifted and held above the ground to
improve the stability and all cutting units will stop rotation. An audible warning
will be given, the buzzer will sound four times every 4 seconds and the red
LED’s will flash four times every 4 seconds. This will continue until the machine
has been driven to an area with a slope less than the value for inhibit lift.
Angle values - Inhibit cut:
HM600 with ROPS 23 deg
HM600 with Cab 21 deg
Press the button below the to confirm the fault.
5.2.Z.60 WARNING OIL-PRESSURE FAULT ____________________________________
When this screen is shown, the engine oil pressure has decreased below the
normal level. If this happens during operation, Stop the engine and check the
oil level.
Top up if necessary. If the problem persists consult your service dealer.
Press the button below the to confirm the fault.
5.2.Z.61 WARNING CLEAR RADIATOR SCREENS _______________________________
When this screen is shown, the engine temperature has risen above the
normal levels.
Park the machine in a safe area disengage cutting units, set engine to idle to
allow engine temperature to decrease prior to switching off the engine.
Clean the radiator and screens of all grass and debris.
Press the button below the to confirm the fault.
WARNING
The slope monitoring system “TST™” (Tilt Sensor Technology) is a slope angle warning system only.
It does not increase the safe working slope beyond that of the declared safe slope.
NOTICE
The number in the top right of the screen indicates the total number of current faults recorded.
If more than one fault, it will cycle all current faults.
!
OIL PRESSURE
FAULT
1
0°
Slopes > = 25°
in either x or y
