19
8. Press Next . The Distance: Antenna Offset From Center will open.
9. Enter the distance the antenna is offset from the center of the implement.
10. Use the Left or Right check boxes to set whether the antenna is mounted to the
Left or Right of the centerline.
11. Press Next . The Distance: Rear Axle to Antenna window will open.
12. Enter the distance from the center of the rear axle to the center of the antenna.
13. Use the Ahead or Behind check boxes to set whether the antenna is Ahead of or
Behind the axle.
NOTE: If configuring CRX for an Articulated machine, select whether the
antenna is in front of or behind the articulation point.
If a Tracked machine, select if the antenna is in front of or behind the
track center.
14. Press Next. For Articulated Tractors, enter The Distance: Rear Axle to Pivot.
NOTE: This allows CRX to calculate the correct position of the implement for
determining the coverage rate and section control functions.
15. Enter the distance from the pivot point to the center of the rear axle.
16. Press Next . The Connection Point Offsets window will open.
17. Enter the Rear Axle to Front Equipment Mount, Rear Axle to Drawn Equipment
Hitch, and Rear Axle to 3 Point Hitch Distances.
18. Press Accept .
DELETE AN EXISTING MACHINE
To delete an existing machine:
1. Press Machine on the CRX settings screen.
2. Select the desired machine.
3. Press Delete . The Confirm Delete Machine window will open.
4. Select Accept to delete the machine or cancel to return to the Select
Machine window.
