DIAGNOSTICS AND TROUBLESHOOTING
DISENGAGE SENSOR
WHEEL ANGLE SENSOR
OPERATOR PRESENCE SWITCH
Display Message
The RS1 disengage sensor is active. The RS1 system
cannot be enabled.
The RS1 disengage sensor is out of range or
disconnected.
The RS1 disengage sensor is inactive. The RS1 system
can be enabled.
Display Message
The wheel angle sensor (WAS) is out of range or
disconnected.
The wheel angle sensor (WAS) is calibrated and ready to
operate.
Display Message
The operator is not present in the seat.
The operator presence switch is disconnected.
The operator presence switch detects the operator. The
RS1 system can be operated.
