Rayjet 8015 - Machine Malfunctions (Error Code Created)

engraving jobs
and cut lines
Ò acceleration too high ¬ reduce acceleration
0 The machine makes
unusual things
Destroyed FRAM parameters
Damaged firmware
Refresh F-Ram parameters
Update the firmware
0 The Axis make the
wrong movements
(
X-Axis make the
movement for the Y-Axis
a
nd inverse )
The jumpers on the motor boards are
interchanged
( The engraving result looks like
mirrored )
Use the right codification on each
Axis
0 Laser head doesn’t
move back to the
exact home
position 0 / 0
Wrong offset is adjusted
Rulers are misaligned
Adjust the offset new in the service
setup
Adjust the rulers fixing
11.2.2 Error code is created
Also see Error Codes above Fehler! Verweisquelle konnte nicht gefunden werden.Fehler!
Verweisquelle konnte nicht gefunden werden..
- Hardware ERROR codes
Error message: Possible reason: Solution:
0 Tracking error X
axis
Ò Faulty X-motor cable
Ò Damaged encoder
Ò Damaged motor driver
Ò Bad wear parts
¬ Replace cable
¬ Replace motor / encoder
¬ Replace driver board
¬ Replace bearings, THK guide or
Belts
0 Illegal limit switch
operation
Ò Damaged limit switch ¬ Replace switch
0 Overcurrent Z axis
Ò High mechanical resistance of table
Ò To heavy material loaded
¬ Clean and oil lead screws
¬ Adjust table
¬ Align lead screws
¬ Move the table without loading
0 Big shift in the
engraving result
Ò Damaged resolver or motor
Ò Bad gearing assembly
¬ Change resolver or motor
¬ Change gearing assembly / X-
Axis service
