Rayjet 8015 - Main Components

Service Manual Rayjet
Main components
General
07/09/2010 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 5 / 53
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, mailto: rayjet@troteclaser.com www.rayjetlaser.com
1 Main components
Top view
Back view
1 keypad
2 top lid
3 maintenance panel
4 service access panel
5 lasertube
6 on/off switch / power socket
7 power supply units
8 electronics
9 connection for PC and exhaust unit
10 connection for exhaust hose
11 product ID lable
1
2
3
4
10
9
5
6
7
8
11
