Videoandalarmaudioconnection
D11682-1
5
6
1
2
3
4
4
3
2
1
1.Display
2.Poweranddatacable
3.Audio/Videocable
4.Videoconnection(x4)
5.VGAconnectiontoexternalmonitor
6.Audioout(lineleveltoappropriateamplier)
Videoconnectioncolors
1Black
2Yellow
3
Green
4Blue
Videoandalarmaudiocables
Thesearethecableswhichprovideconnectionsforvideodevices,
anexternalmonitorandanalarmaudiosignal.
Cablesandconnections43
