Removingthefrontbezel
D11 19 7-2
1
2
3
Important:Usecarewhenremovingthebezel.Donotuseany
toolstoleverthebezel,doingsomaycausedamage.
1.Uncliptheloweredgeofthebezel.Startingatthelower-center
edgeandworkingtowardstheouteredges,
2.Unclipthelefthandedgeworkingfromthebottomcorner
upwards.
3.Uncliptherighthandedge.
Thebezelshouldnowcomeawayfromthedisplayeasily.
52E-SeriesWidescreeninstallation
