9.4Sparesandaccessories
OptionsandaccessoriesfortheE-SeriesWidescreenMultifunction
displays.
Optionalaccessories
DescriptionPartNoNotes
Trunnion(bracket)
mountkit(C90W/
E90W)
A62132
Trunnion(bracket)
mountkit(C120W/
E120W)
A62133
DescriptionPartNoNotes
Trunnion(bracket)
mountkit(C140W/
E140W)
A62134
5m(16.4ft)Audio/Video
cable
A62158Availableasan
accessory.
Thiscableprovides:
•3xvideoinputBNC
connectors
•1xVGAvideooutput
connector
•1xRCAphono
jackplug(foralarm
signallingonly)
Note:5m(16.4
ft)lengthisforthe
VGAyingleadonly.
Allotherconnectors
areonleadsof0.5m
(1.6ft)length.
Spare/replacementparts
DescriptionPartNoNotes
TrunnionknobR08001
Suncover(C90W/
E90W)
R62122
Optionsandaccessories
89
