Raymarine E90W - Selecting a Location

4.1Selectingalocation
Warning:Potentialignitionsource
ThisproductisNOTapprovedforusein
hazardous/ammableatmospheres.DoNOTinstallin
ahazardous/ammableatmosphere(suchasinan
engineroomornearfueltanks).
Generallocationrequirements
Whenselectingalocationforyourdisplayitisimportanttoconsider
anumberoffactors.
Keyfactorswhichcanaffectproductperformanceare:
•Ventilation
Toensureadequateairow:
–Ensurethatequipmentismountedinacompartmentofsuitable
size.
–Ensurethatventilationholesarenotobstructed.Allow
adequateseparationofequipment.
Anyspecicrequirementsforeachsystemcomponentare
providedlaterinthischapter.
•Mountingsurface.
Ensureequipmentisadequatelysupportedonasecuresurface.
Donotmountunitsorcutholesinplaceswhichmaydamagethe
structureofthevessel.
•Cableentry
Ensuretheunitismountedinalocationwhichallowsproper
routingandconnectionofcables:
–Minimumbendradiusof100mm(3.94in)unlessotherwise
stated.
–Usecablesupportstopreventstressonconnectors.
•Wateringress
Thedisplayissuitableformountingbothaboveandbelowdecks.
ItiswaterprooftoIPX6standard.Althoughtheunitiswaterproof,
itisgoodpracticetolocateitinaprotectedareaawayfrom
prolongedanddirectexposuretorainandsaltspray.
•Electricalinterference
Selectalocationthatisfarenoughawayfromdevicesthat
maycauseinterference,suchasmotors,generatorsandradio
transmitters/receivers.
•Magneticcompass
Selectalocationthatisatleast3ft(1m)awayfromamagnetic
compass.
•Powersupply
Selectalocationthatisascloseaspossibletotheboat’sDC
powersource.Thiswillhelptokeepcablerunstoaminimum
Adequatespaceforcoolingns
Ensureadequatespacearoundthecoolingns,inparticularyou
mustavoidcontactwithanymetalobjectorsurface.
Boththecoolingnsontherearofthedisplayandthescrews
securingthemMUSTNOTbeincontactwithanymetalobjects
includinganymetallicpartofthevesselstructure.Failuretoadhere
tothiscouldresultinunwantedcurrentowandinturndamage
tothevesselstructurethroughtheprocessofgalvaniccorrosion.
Ifthisisaconcernthenthemethodofmountingmustensure
electricalisolation.
Viewingangleconsiderations
Asdisplaycontrast,colorandnightmodeperformanceareall
affectedbytheviewingangle,Raymarinerecommendsyou
temporarilypowerupthedisplaywhenplanningtheinstallation,to
enableyoutobestjudgewhichlocationgivestheoptimumviewing
angle.
