Talkngtostripped-endspurcables(Connectscompatibleproductthatdonothavea
SeaTalkngconnectorsuchastransducerpods):
•1m(3.3ft)SeaTalkngtostripped-endspurcable—A06043
•3m(9.8ft)SeaTalkngtostripped-endspurcable—A06044
5.0.3m(1.0ft)ACU/SPXautopilottoSeaTalkngspurcable(R12112).Connectsthecourse
computertotheSea Talkngbackbone.Thisconnectioncanalsobeusedtoprovide12Vdc
powertotheSeaTalkngbackbone.
SeaTalkng®backbonecables
SeaTalkngbackbonecablesareusedtocreateorextendaSeaTalkngbackbone.
•0 .4m(1.3ft)Backbonecable(A06033).
•1m(3.3ft)Backbonecable(A06034).
•3m(9.8ft)Backbonecable(A06035).
•5m(16.4ft)Backbonecable(A06036).
•9m(29.5ft)Backbonecable(A06068).
•20m(65.6ft)Backbonecable(A06037).
SeaTalkng®powercables
SeaTalkngpowercablesareusedtoprovidetheSeaTalkngbackbonewithasingle12Vdcpower
source.Thepowerconnectionmustincludea5ampinlinefuse(notsupplied).
1.2m(6.6ft)P owercable(straight)(A06049).
2.2m(6.6ft)Elbow(rightangled)powercable(A06070).
SeaTalkng®connectors
SeaTalkngconnectorsareusedtoconnectSeaTalkngdevicestotheSeaTalkngbackboneand
tocreateandextendthebackbone.
1.5-W ayconnector(A06064).Eachconnectorblockallowsconnectionofupto3SeaTalkng
devices.Multipleconnectorblockscanbe‘daisychained’together.
2.T-piece(A06028).EachT-pieceallowsconnectionofoneSeaTalkngdevice.MultipleT-pieces
canbe‘daisychained’together.
3.Backboneextender(A06030).Usedtoconnect2backbonecablestogether.
4.Inlineterminator(A80001).UsedtoconnectaspurcableandSeaTalkngdeviceattheendofa
backboneinsteadofabackboneterminator.
