RT-7200 Auto Hematology Analyzer User’s Manual
Main graphical representations used on this instrument
Temperature limitation
Fragile articles
The fragile articles are contained in the transport package, so it
should be handled with care when being transported
Upwards
It indicates that the transport package shall be kept vertically
upward
To be protected from rain
The packaging piece is extensive to the rain
Limit of the number of stacking tiers
It indicates the maximum number of the stacking tiers of the
same package. 3 indicate the limit of the stacking tiers.
Biological risks
This means that the labeled item could lead to personal
injury and/or damage to the analyzer. The symbol is labeled
beside the power outlet and some external interface.
Serial number
In vitro diagnostic medical device.
Manufacturer
Authorised representative in the European community
3
