Extra blow Set the assist gas type for piercing. There are the air, oxygen, and nitrogen.
Extra blow（bar）
It refers to the time of no laser and blowing gas only for cooling the plate after piercing, which
reduces the impact of the plate hotting to the next process.
3.9 Advanced Parameter
Click on Adv. next to Cut and Pierce. There will display the interface of setting advanced parameters, as shown below:
Advanced Parameter
Vibration (Vibratio.)
Suppression
There may leave slags on the plate after piercing a thick plate. The vibration suppression can
improve the cutting effect.
The suppression is used for both thin and thick sheets. Please select the type according to
your need
SuppresType
.
Level The higher the level of suppression, the slower the response is.
