XC3000Series Motion Control System of Laser Cutting - User Manual
V1.0 Raytools AG © Copyright 58 |87
www.raytools.ch
3.11 Import and Export
To import or export the process parameters of the layer, users should note that the button will only use to import or
export the process of the current layer. For example, if using both layers of large and medium contours, clicking on Export
button in the layer of large contour will only export the process parameters of it. Them same applies to the import. Select
the needed layer and then import or export.
3.12 Global Parameter
Global parameter mainly includes Motion Control Parameter, Default Parameter, Unit Selection, Prepiercing and Defilm.
Adjustment of these parameters will affect the stability of machine operation, processing effect and efficiency.
Motion Control Parameter
Parameter Default Remark
Travel speed 30
The travel speed of the X/Y axis from one contour to another in cutting.
(Set the X and Y axis to be the same or separate with different parameters at
the bottom of Motion Control Parameter.)
Travel acc
The travel acceleration of the X/Y axis from one contour to another in
cutting.
(Set the X and Y axis to be the same or separate with different parameters at
the bottom of Motion Control Parameter.
6000
)
Travel acc time 100
The travel acceleration time of the X/Y axis from one contour to another in
cutting. The more the time, the slower the acceleration, which brings less
impact to the machine. The less the time, the faster the acceleration, which
brings more impact to the machine.
(Set the X and Y axis to be the same or separate with different parameters at
the bottom of Motion Control Parameter.)
Frame speed 18 Set the speed of framing.
Cutting acceleration 5000
Cutting acceleration is the maximum speed of each axis motion when
cutting and used in conjunction with the cutting speed.
Cutting acc time
The more the cutting acceleration time, the slower the acceleration, which
brings less impact to the machine. The less the time, the faster the
acceleration, which brings more impact to the machine
100
.
Low pass filter coefficient 20 The default is fine, and modify it if there are any special circumstances.
Corner speed coefficient 1 The default is fine, and modify it if there are any special circumstances.
Arc speed coefficient 1 The default is fine, and modify it if there are any special circumstances.
XY axis travel setting Same Set the X and Y axis to be the same or separate with different parameters.
