12 Chapter 1
Connections & Setup
TAPE
VCR
IN OUT IN
OUT
CD
IN
TV
IN
R
L
A/V RECEIVER
DIGITAL
AUDIO OUT
R
L/ MONO
VIDEO
ANTENNA
S-VIDEO
TV/DVD
OUT
R
L
IN
G-LINK
CABLE OR
OFF-AIR SIGNAL
DIGITAL IN
DOLBY DIGITAL
or DTS RECEIVER
-OR-
T
V
/
D
V
D
Dolby Digital
®
and DTS
®
Both Dolby Digital and DTS are audio formats used to record 5.1-channel audio signals onto the
digital track of film (while the film is being made). Both of these formats provide up to six separate
channels: left, right, center, left rear, right rear, and common subwoofer.
The disc will play 5.1-channel sound only if you’ve connected a DTS or Dolby Digital receiver or
decoder and if the original movie the disc was recorded from was encoded in the Dolby Digital or
DTS format.
Please Read This Before Using the DIGITAL AUDIO OUT Jack!
This unit’s digital output jack is designed for a connection to a Dolby Digital or DTS receiver or decoder.
Older digital equipment may not be compatible with the Dolby Digital bitstream. Such a connection can
create a high level of noise that may be harmful to your ears, and could damage headphones or speakers.
It is important to choose the correct Digital Output setting in the DVD Player’s Sound menu, especially when
you use the DIGITAL AUDIO OUT jack. For more information, see Chapter 4.
R
e
c
e
i
v
e
r
*Dolby Digital is a trademark of Dolby Laboratories Licensing Corporation
**DTS is a registered trademark of Digital Home Theater Systems, Inc.
1
3
Note: The back of your Dolby Digital* or DTS** receiver might not
look exactly like the one shown here.
2A
2B
To Next Page
