RCm BIT 391CB - Connecting the Batteries (for BC Version Only; Electrical Connection (for E Version Only

Fig. 4
4
5
6
EN
EN-8
3.1.b - Connecting the batteries
(for BC version only) (Fig. 4
- Remove the recovery water tank (4) and
connect the battery connectors (5 and
6).
- Replace the recovery water tank (4).
3.1.c - Electrical connection
(for E version only)
- Connect the machine power cable to a
mains socket with a minimum capacity of
10A.
WARNING:
- Make sure that the mains system is
equipped with an RCD (circuit break-
er).
- Unwind the electric power cable com-
pletely before operating the appliance.
- Use an electrical extension lead only
if in perfect condition; ensure that the
section is appropriate for the appliance
power rating.
- Never let the power cable run over
sharp edges and do not tread on it.
