RCm BIT 391CB - Cleaning the Squeegee

Fig. 16
1
1
2
3
1
4
5
EN
EN-20
11.1.c - Cleaning the squeegee (Fig.
16)
In order to clean the squeegee correctly (1),
it is necessary to remove it as follows:
- Pull the squeegee unit outwards (1).
- Disconnect the hose (2) from the squee-
gee (1).
- Loosen the knobs (3) and remove the
squeegee (1).
- Wash the squeegee and in particular the
rubber blades (4) and the inside of the as-
piration connector (5).
N.B.:
If, during washing, it is clear that the rubber
blades (4) are damaged or worn, it is neces-
sary to replace them or turn them over.
- Replace all the components in reverse
order.
