Fig. 8
1
2
Fig. 9
EN
EN-13
7.1 LEVER FOR HANDLE
ANGLE
REGULATION (Fig. 9)
- By pulling on the lever (1), it is possible to
vary the position of the handle (2);
releasing the lever, the handle is posi-
tioned and locks in the nearest required
position.
N.B.:
By positioning the handle (2) vertically, it is
possible to effect a more thorough cleaning
of corners by rotating the machine on itself.
