TROUBLESHOTTING
Problem Cause Corrective action
The sweeper fails to pick up large particles of dirt or
leaves traces of dirt behind
Brush speed too slow Increase hydraulic motor speed
Working speed too fast Reduce working speed
Brush pressure too light Adjust brush pressure (trace on  oor)
Brush worn Replace brush
Bristles bent, or string or wire, etc., entangled in brush Remove string or wire
Dust guide plate encrusted with pressed material Clean using an iron spatule
Sweeper leaves dust on  oor or dust comes out from
side  aps
Vacuum fan faulty Check fan
Bin detached from fan mouth Close the bin tight
Filter clogged Clean  lter
Flaps worn Replace  ap
Dust inside the  lter housing
Filters broken Replace
Seals of  lter housing worn Replace
Sweeper fails to pick up paper, leaves, etc. Front  ap raiser not working Check or in case repair
The sweeper throws dirt forwards Front  ap broken Replace
Rapid brush wear
Excessive brush pressure Reduce brush pressure (narrower trace)
Floor very abrasive
Main brush noisy Material wound around brush Remove
The brushes fail to turn
No oil in circuit system Add oil
Oil cock shut o Open cock
Pressure too low in circuit Adjust pressure
Brush drive motor not functioning Replace
Pump or seals are damaged Replace seals or pump
Refuse bin does not rise
Bin overfull Empty more frequently
Low pressure in the circuit (should be 130 atm.) Increase pressure
Piston seals faulty Replace
Pump or seals are damaged Replace seals or pump
Refuse bin lowers in jerks
Hydraulic oil in circuit poor Add hydraulic oil
Hydraulic oil  lter clogged Replace
Level low inside the hydraulic oil tank Top up level
Dust and waste come out of bin
Seal door faulty Replace seals
door not closed Take lever 6 to pos. B ( g.1)
Refuse bin lowers by itself
cylinders seals faulty Replace
valve faulty Replace
Rear door bin opens by itself cylinders seals faulty Replace seals
The sweeper does not move, or moves slowly
hydraulic circuit without oil Add oil
Oil cock shut o Open cock
By-pass open Close
Hydraulic oil  lter clogged Replace
Front wheel hydraulic oil motor damaged Replace
Delivery pump or its seals damaged Replace seals or pump
The sweeper moves even with the drive pedal in neutral Travel pedal recall cylinder badly set Adjusting cylinder
Excessive backlash on steering wheel Chain slack Adjusting the chain tension
The engine cooling liquid indicator illuminates (Koh-
ler and Kubota engine)
Engine water cooler  ns fouled Clean cooler  ns
Engine cooling liquid level too low Top up level
