1 SAFETY INSTRUCTIONS
2 INSTALLATION
3 WIRING
4 COMMISSIONING
5 SETTINGS RADAR MOTION DETECTOR “RAD”
6 SETTINGS ON PRESENCE DETECTOR “AIR”
7 DETAILS PARAMETER MOTION DETECTOR “RAD”
8 DETAILS PARAMETER PRESENCE DETECTOR “AIR”
9 FUNCTIONS
10 OVERVIEW OF ALL PRE-PROGRAMMED SCENES
11 LED SIGNALS
12 FINISH
13 MAINTENANCE
14 POSSIBLE INTERFERENCES
15 DIAGNOSTICS
16 TECHNICAL DATA
ABBREVIATIONS
AKA Actuation contact outside
AKI Actuation contact inside
AIR Active infrared presence detector
AIS Safety sensor for side screen protection
EPC Easy-Programmer
FEM Function extension module
FPC Service- and Flash programmer
IR Infrared
LED Light emitting diode
RAD Radar motion detector
RIC Combi sensor (radar infrared combined)
SA Safety sensor outside
SFT Sensor functional button
SI Safety sensor inside
STM Door control module
Note
Especially useful details concerning installation.
Attention
Special details essential for the satisfactory operation of the system.
Caution
A possibly dangerous situation, which could lead to light injury and material damage.
Warning
An imminent dangerous situation, which could lead to severe or fatal injury and cause extensive material damage.
14
Cross-reference to other chapter
Symbols
