Record RIC 290 - RAD Pre-programmed Scenes

RAD
BDE-D, FPC 902:
Values in brackets ( )
No. Scene Passage width Installation height Install. position Antenna angle Remarks
1
(0)
Standard
< 6’7”
7 up to 8’6” Surface mounted 5 -10°
Installation height > 8’6” change to
narrow field characteristic
2
(1)
Supermarket
> 6’7”
7 up to 8’6” Surface mounted 5 -10°
Installation height > 8’6” change to
narrow field characteristic
3
(2)
Nursing home
as required 7 up to 8’6” as required 5 -10°
Installation height > 8’6” change to
narrow field characteristic
4
(3)
Pavement as required
7’
as required 5 -10°
5
(4)
Niche as required
7’
Surface mounted 0°
Pre-programmed scenes for radar motion detector “RAD”
5.4
