Record RIC 290 - CAN Bus Error Display

Those error numbers consist of 4 digits as follows:
• Digits 1 + 2 indicate the reason of the error
• Digits 3 + 4 specify the name of the unit
Example: error number 1616 means that sensor AKI 1 does
not have any teaching parameter and a teach-in run has to
be performed.
Digits Display text Comments Possible troubleshooting
1+2 3+4
11 -- CAN node not found CAN connection interrupted Control connection
12 -- CAN connect.(SEND) Send CAN connection Control connection
13 -- CAN connect.(RECV) CAN connection received Control connection
14 -- EEPROM defective EEPROM faulty Load factory settings. Replace unit
15 -- EEPROM void EEPROM empty Load factory settings. Replace unit
16 -- No running parameter No teaching parameters available Perform teach-in run
17 -- HW defective Hardware faulty Replace unit
18 -- Redundancy path Redundant radar sensor faulty Reset or restart control unit
19 -- Background check The background is not appropriate for this sensor or installation is too high, or
weak IR light intensity
Check/reduce installation height, disable function. Error in IR part, replace unit.
20 -- Software error An error has arisen in the software of the external unit. Carry out a new start. If the error is still active after this, the unit must be replaced.
21 -- CAN connection blocked The anti-burglary protection has responded and locked the
CAN connection to the
external unit.
If the door is locked, no external units, such as BDE-D, FPC and FEMx, may be connected to
the CAN bus. Unlock door, briefly press MFT key or actuate the EMERGENCY STOP switch.
22 -- SAFETY_LEVEL The AKI sensor is not allowed for the security level required by the RED door
controller.
Replace sensor with an appropriate redundant sensor.
23 --
24 --
-- 08 SENS SI 1 SI 1 Presence detector inside 1
-- 09 SENS SI 2 SI 2 Presence detector inside 2
-- 10 SENS SA 1 SA 1 Presence detector outside 1
-- 11 SENS SA 2 SA 2 Presence detector outside 2
-- 12 SENS SL SL Side surveillance left
-- 13 SENS SR SR Side surveillance right
-- 16 SENS AKI 1 AKI 1 Actuating device inside 1
-- 17 SENS AKI 2 AKI 2 Actuating device inside 2
-- 18 SENS AKA 1 AKA 1 Actuating device outside 1
-- 19 SENS AKA 2 AKA 2 Actuating device outside 2
-- 32 FPC Service unit FPC902
--
--
Error display of additional units on CAN bus (only with FPC)
15.2
