4.1
Locks in four 5° angle posi
Release of the position pin by
gently pressing the right side
clip outwards.
Adjust mechanical settings
before programming.
Locks in three 10° angle posi-
tions. Release of the pivot frame
by gently pulling the clip below.
For emergency exits the detec-
tion field must begin min. 43 in.
in front of the door.
5
SETTINGS RADAR MOTION DETECTOR “RAD”
Adjust angle of inclination to position the activating detection zone
5.1
Lateral field adjustment of the antenna
5.2
Field depth in exit routes
5.3
Quick parameter settings with scene selection
