Record RIC 290 - Technical Data; General Specifications; RAD Detector Specifications; AIR Detector Specifications

In general:
Supply voltage: 11...31 VDC
Connected load: < 2 W
Installation height max.: 9’10”
outstanding of the standards: < 13’1”
Max. fuse protection if separately supplied: 2.5 A
Protection class: IP 54
Temperature range: –4...+ 122 °F
Cable length (102-020808406): 8’2”
Motion detector RAD
Frequency (K-Band): 24.125 GHz
Power output: < 10 mW
Detection capability: 28” min. high person
moving at a rate of 2 in. per s min.
Performance level: PL „d“, Cat. 3
Response time, max. < 50 ms
Presence detector AIR
Wavelength infrared: 870 nm
Detection capability: stationary 8” min. high object
for a min. of 30 s
Performance level: PL „c“, Cat. 2
Response time, max. < 500 ms
Type label
Year of manufacture
YYMMDD
Dimensions
TECHNICAL DATA
RIC 290 A
16
