Pro gram ming of the in di ca tor is di vided into modu lar steps. Each mod ule
is a short se quence of data en tries. The front panel but tons “UP” and
“DOWN”, (shown as “ar rows” on the front panel) are used to change the
data and set- ups, while the “P” but ton is used to save or en ter the data. Af ter
press ing “P” which gains en try into the pro gram ming mode, the
pro gram ming mod ules are iden ti fied by the mes sage “Pro” and a number in
the dis play. “UP” and “DOWN” are used to se lect the de sired pro gram ming
mod ule and “P” is used to en ter it. All of the sub se quent pro gram ming steps
fol low the same pro ce dure. The rear ter mi nal la beled “PGM. DIS.” must be
un grounded to gain ac cess to pro gram ming.
The fol low ing ta ble lists the pro gram ming steps.
“Pro 0” - RE TURN TO MEAS URE MENT MODE
“Pro 1” - SCALE UNIT BY AP PLY ING SIG NAL
“ dECPNt” - En ter dec i mal point for scaled dis play
“round” - En ter round ing fac tor and trail ing ze ros for scaled dis play
“SCALE” - *
“dSP 1” - En ter dis play read ing for scal ing point #1
“INP 1” - Ap ply sig nal level for scal ing point #1
“dSP 2” - En ter dis play read ing for scal ing point #2
“INP 2” - Ap ply sig nal level for scal ing point #2
“SEGt” - *
“Pro 2” - SCALE UNIT BY KEY- IN SIG NAL LEVEL
“ dECPNt” - En ter dec i mal point for scaled dis play
“round” - En ter round ing fac tor and trail ing ze ros for scaled dis play
“SCALE” - *
“dSP 1” - En ter dis play read ing for scal ing point #1
“INP 1” - En ter sig nal level for scal ing point #1
“dSP 2” - En ter dis play read ing for scal ing point #2
“INP 2” - En ter sig nal level for scal ing point #2
“SEGt” - *
* - En tire se quence for this modu lar step is not shown (see re spec tive
pro gram ming mod ule for fur ther de tails).
> This se quence may be sub ject to be ing locked- out due to other programmed
se quences.
“Pro 3” - PRO GRAM FUNC TIONS AC CES SI BLE WITH FRONT
PANEL LOCK OUT EN GAGED
“dSP AL” - En able dis play alarms
“ENt AL” - En able en ter alarms >
“dSPHYS” - En able dis play hys ter esis
“ENtHYS” - En able en ter hys ter esis >
“rSt AL” - En able re set latched alarms
“dSPbUF” - En able dis play of peak/val ley read ings
“rStbUF” - En able re set of peak/val ley read ings >
“SELdSP” - En able switch ing dis play be tween in put and to tal
“rSttOt” - En able re set to tal
“tArE” - En able re-zero (tare) of in put sig nal
“Pro 4” - PRO GRAM DIGI TAL FIL TER ING AND RE MOTE IN PUT
FUNC TION
“FIL tEr” - En ter level of dig i tal fil ter ing
0 - no dig i tal fil ter ing
1 - nor mal fil ter ing
2 - in creased fil ter ing
3 - max i mum fil ter ing
“E1-CON” - En ter func tion of re mote in put (Re set/Hold)
0 - re-zero in put
1 - re set to tal
2 - re set and gate totalizer
3 - gate totalizer
4 - dis play hold
5 - re set peak/val ley
6 - re set peak and start peak in di ca tor
7 - re set val ley and start val ley in di ca tor
8 - re set latched alarms
9 - re set all alarms
10 - tog gle dis play be tween in put and to tal
11 - re-zero in put and totalize the tared val ues
12 - dis play hold with tare
13 - in stru ment read ing synchronization
14 - print re quest
“E2-CON” - Same func tions as E1-CON
