Redball 680 - Page 109

11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
Description: 8-Bolt Adjustable Axle Assembly
58
Section F
1 004500* Spindle Weld; Short 2
007392* Spindle Weld; Long
2 004902* Weld; Axle 62” - 80” (Single) 1
007388* Weld; Axle 88” - 120” (Single)
004898* Weld; Axle 120” - 152” (Single)
3 BH-075-250-5 Bolt; 3/4 x 2 1/2 Gr. 58
4 BU075-500-900-5 U-Bolt; 3/4 x 5 x 9 Gr. 5 8
5 LN-075-NI Locknut; 3/4 Nylon Insert 24
6 BH-050-500-5 Bolt, 1/2” x 5” Hex. Gr. 5 1
7 LN-050-NI Locknut, 1/2” Nylon Insert 1
8 004544 Spindle 680 1
9 P602122 Grease Seal 1
10 P752320 Inner Cone 387-AS 1
11 P702217 Inner Cup 382-A 1
12 P151407 Stud Bolt; 5/8-18 UNF 8
13 Machine Casting 1
14 P702204 Outer Cup, LM501310 1
15 P752306 Outer Cone, LM501349 1
16 P401902 Cotter Pin, 7/32” x 1 3/4” Spindle 1
17 P301806 Flat Washer, 2 1/8 x 1 1/16 x 1/4 Spindle 1
18 P251706 Nut, Spindle, 1”-14 1
19 P502008 Hub Cap 1
20 P201601 Wheel Nut 5/8-18UNF 8
21 184R38-10TIRE 18.4 x 38 Tire/Rim (Single) 1
320-85R38TIRE Tire Only; 320 -85R38
320-90R46TIRE Tire Only; 320-90R46
22 T-047-3197* Complete Hub Assembly
23 184R38WHEEL* Wheel; 38 x 16, 8-8-6
320-85R38WHEEL* Wheel; 38 x 10
320-90R46-8WHEEL* Wheel; 46 x 10
Item# Part # Description Quantity
**Specify Color
Note: Specify whether tire is for left or right side.
