Redball 680 - 10-Bolt Adjustable Axle Assembly

11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
Description: 10-Bolt Adjustable Axle Assembly
59
Section F
1 007166* Spindle Weld; Short 2
007333* Spindle Weld; Long
2 006161* Weld; Axle 62”-80” (Single) 1
007327* Weld; Axle 80”-120” (Single)
006163* Weld; Axle 120”-152” (Single)
006222* Weld; Axle (Dual)
3 BH-075-250-5 Bolt; 3/4 x 2 1/2 Gr. 5 8
Item# Part # Description Quantity
Ref-006268D
