11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
Description: 10-Bolt Adjustable Axle Assembly
60
Section F
4 BU075-500-900-5 U-Bolt; 3/4 x 5 x 9 Gr. 5 8
5 LN-075-NI Locknut; 3/4 Nylon Insert 24
6 BH-050-500-5 Bolt, 1/2” x 5” Hex. Gr. 5 1
7 LN-050-NI Locknut, 1/2” Nylon Insert 1
8 2813180L16 Spindle 680 10-Bolt 1
LS5545K-00 Spindle 680 10-Bolt (Duals Only)
9 2891300* Complete Hub Assembly 1
10 906497 Grease Seal 1
11 910333 Inner Cone 1
P752336 Inner Cone (Duals Only)
12 910331 Inner Cup 1
13 913564 Stud Bolt 3/4 - 16 UNC (Single) 10
953033 Stud Bolt 3/4 - 16 UNC (Dual)
14 Machine Casting 1
15 910332 Outer Cone 1
16 910334 Outer Cup 1
17 905944 Cotter Pin, Spindle 1
18 913632 Flat Washer, Spindle 1
19 912969 Nut, Spindle, 1 1/4” - 12 1
20 905205 Bolt, Dust Cap 4
21 909983 Dust Cap 1
22 913571 Wheel Nut 3/4” - 16 UNC Flanged 10
23 149R46-8TIRE Tire Only; 48E832
230-90R46TIRE Tire Only; 320-90R46, 49V7V8
24 270-95R48-22* 270/95 x R48 - 22” Tire/Rim (Dual) 2
149R46RU* 14.9 x 46 - 30” Tire/Rim (Dual)
25 149R46WHEEL* Wheel; 46 x 12, 10 Bolt 1
320-90R46-10WHEEL* Wheel; 46 x 10, 10 Bolt
Item# Part # Description Quantity
**Specify Color
Note: Specify whether is for left or right and if inner or outer for dual setup.
