Redball 680 - Page 55

11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
4
Section F
Description: Complete Frame
1 004000 Frame, 750 Gal. Weld 1
004100 Frame, 1000 Gal. Weld
004125 Frame, 1350-1600 Gal. Weld
2 004065 Plate, L.H. Cover 1
3 004066 Plate, R.H. Cover 1
4 004090 Panel, Valve Mount 1
5 004096 Stop, Ladder 2
6 004845 Weld, Sight Gauge (750, 1000, 1350) 1
006216 Weld, Sight Gauge (1600)
7 004167 Plate, Gauge Mount 1
8 004245 Weld, Safety Stand (Rear) 1
9 004315 Stop, Cylinder Assembly 1
10 004435 Weld, Lower Parallel 2
11 004455 Weld, Ladder 1
12 004540 Weld, 6” Pin 4
13* 004555 Mount, Valve 3 1/2” 4
14 004556 Mount, Valve 2 1/2” 2
15* 004557 Mount, Valve 3” 6
16 004592 Door, Storage Box (L.H.) 1
17 004593 Door, Storage Box (R.H.) 1
18 004594 Door, Valve Box 1
19 007467 Weld, Upper Parallel 1
20 0750 Tank, 750 Gal. Redball 680 1
1000 Tank, 1000 Gal. Redball 680
1350 Tank, 1350 Gal. Redball 680
1600 Tank, 1600 Gal. Redball 680
21 6000-01Y Tank, 100 Gal. Rinse, Redball 680 1
22 6000-02Y Tank, 20 Gal. Safety, Redball 680 1
23 006039 Weld, Fresh Water Riser (1600 Only) 1
24 BC-025-075-2 Bolt, 1/4 x 3/4 Carriage 20
25 BH-025-075-2 Bolt, 1/4 x 3/4 Hex. Gr. 2 4
26 BH-025-200-2 Bolt, 1/4 x 2 Hex. Gr. 2 3
27 BH-025-250-5 Bolt, 1/4 x 2 1/2 Hex. Gr. 5 1
28 BH-031-075-2 Bolt, 5/16 x 3/4 Hex. Gr. 2 22
29 BH-038-125-2 Bolt, 3/8 x 1 1/4 Hex. Gr. 2 1
30 BH-10/24-075-2 Bolt, Mach. Hex 10/24 x 3/4 9
31 BH-100-850-5 Bolt, 1 x 8 1/2 Hex. Gr. 8 4
Item# Part # Description Quantity
* NOT SHOWN
SPECIFY COLOR WHEN NEEDED
