11-01
5
Section F
680 High Clearance Sprayer - Parts & Schematics
Section F
Description: Complete Frame
32 BM-10/24-050 Bolt, Mach. 10/24 x 1/2 PH-Pan 2
33 BU031-100-175-2 U-Bolt, 5/16 x 1 x 1 3/4 Gr. 2 Sq. 1
34 BU038-200-300-2 U-Bolt, 3/8 x 2 x 3 Gr. 2 Sq. 2
35 E3-41-15 Handle, Sprayer 3
36 FW-031 Flatwasher, 5/16 6
37 HPC-210 Pin Clip, 2 3/16 x 7/8, Leg Stand 2
38 LN-025-NI Locknut, 1/4 Nylon Insert 10
39 LN-031-NI Locknut, 5/16 Nylon Insert 2
40 LN-038-NI Locknut, 3/8 Nylon Insert 5
41 LN-10/24-NI Locknut, 10/24 Nylon Insert 11
42 LN-100-NI Locknut, 1 Nylon Insert 4
43 LW-031 Lockwasher, 5/166
44 NTF-025 Nut, 1/4 - 20 Serrated Flanged 20
45 UNUT-031 Nut, U-Shaped 5/16 -18 14
46 PCL-050-350 Pin, 1/2 x 3 1/2 Clevis Pin-Zinc 2
47 PLI-031-250 Linch Pin, 5/16 x 2 1/2 2
48 1253 Spigot, Natural 3/4” 1
49 200972 Cover, 3 1/2” Anhy. Screw Cap 1
50 A3412 Hose Fitting, 3/4MPT x 1/2HB 2
51 EL3412 Hose Fitting, 3/4MPT x 1/2HB 2
52 G Clamp, Speedy Fits 1/2” EVA 1
53 SIGHT-12 Hose, 1/2”ID x 1/8 Wall Sight
54 352160-1 Cover, 16” w/Lid and Rim 1
55 171-C Screws 8
56 354010 Cover, 6” w/Vent Removed 1
57 HB-075-90 Hose Barb Ell, 3/4MPT x HB Poly 1
#12J Clamp, 3/4” Stainless Clamp 5
SIGHT-34 Hose, 3/4” Clear Sight
3EL34HBG Hose Fitting, 3/4 ELHB x 3/4 HB 1
001212 Hose, 3/4” 150# EPDM, L85
HB-075 Hose Barb, 3/4MPT x 3/4 HB Poly 1
58 001131 Anti-Vortex Fitting1
59 NW60401 Bulkhead Fitting 3/4” 1
60 0254-1035 Rope, 1/8 Poly 1
61 #4JM Clamp; 1/4" x 5/16" Stainless 3
62 HB-025-038 Hose Barb; 1/4" MPT x 3/8" HB 1
63 HB-025-038-90 Hose Barb; 1/4" MPT x 3/8" HB El 1
64 SIGHT-38 Hose; 3/8" x 1/16" Clear Sight
65 3EL38HB Hose Fitting; 3/8 ELHB x 3/8 HB 1
66 F Clamp; Speedy, Fits 3/8" Hose 2
Item# Part # Description Quantity
SPECIFY COLOR WHEN NEEDED
