Redball 680 - Page 75

11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
14 90-50143 844-E Core Kit, Console, Manual, Mt Brket 1
48348 TeeJet 844-E; Console Only 1
15 004114 Plate Strainer Bracket 1
16 4030-0016 Hose Barb, 1/4 FB3 1
17 4030-0017 Hose Barb, 1/8 B3 1
18 4030-0018 Tubing, 3/16” x.124ID Yellow 1
19 ASG1604-REDBALL Gauge, 4”, 160 PSI, Ammonia 1
20 BC-025-075-2 Bolt, 1/4” x 3/4” Carriage 1
21 BH-025-075-2 Bolt, 1/4” x 3/4” Gr. 2 1
22 BH-038-300-2 Bolt, 3/8” x 3” Gr. 2 1
23 FC100BJ Clamp, 1” For Flanged Valves 1
24 FC200BJ Clamp, 2” For Flanged Valves 1
25 HB-075-100-90 Hose Barb Ell, 3/4MPT x 1 HB Ell 1
26 HB-100-90 Hose Barb Ell, 1MPT x HB Poly 1
27 LN-025-NI Locknut, 1/4” Nylon Insert 1
28 LN-038-NI Locknut, 3/8” Nylon Insert 1
29 M100125BRB Hose Barb, 1” Flange x 1 1/4 Barb 1
30 M100BRB Hose Barb, 1” Flanged Straight 1
31 HB-075-100 Hose Barb, 3/4” MPT x 1” Barb 1
32 M100G Gasket, 1” Flanged Valves 1
33 M100MPT Manifold, 1” x 1” Male Thread 1
34 M100TEE Tee, 1” Manifold Tee, Flanged 1
35 M200/100TEE Manifold Tee, 2” x 1” 1
36 M200/125BRB Hose Barb, 2” x 1 1/4” Straight 1
37 M200PLG025 Plug, Flange 2” w/1/4” Port 1
38 MVE100CF Ball Valve, 1” Flanged Elec. 1
39 RB1418-SS Reducer Bushing, 1/4” MPT x 1/8” FPT 1
40A V-075 Valve, 3/4” Bolted Ball Valve 1
40B VT-075 Valve, 3/4" Bolted Ball Valve
41 12012 Hose, 1 1/4" 150# Black Rubber 1
42 UB200 U-Bolt For Banjo Ball Valve 1
43 #20J Clamp, 1 1/4" Stainless 1
44 004108 Plate, Strainer Mount 1
Item# Part # Description Quantity
Description: TeeJet
®
844 Controller, Banjo
®
Valves (Optional)
24
Section F
*Not Shown
+ Available as Kit P/N 007312
