Redball 680 - Page 87

11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
1 M220MPT 2” Manifold x 2” Full Port 1
2 #16J Clamp, 1” Stainless Clamp 20
3 #20J Clamp, 1 1/4” Stainless Clamp 2
4 #36J Clamp, 2” Stainless Clamp 19
5 MV220CF Valve, 2” FP Flanged Valve 1
6 004450 Mount, Diaphragm Pump (Black) 1
7 011612 Hose, 1” 150# Black Rubber
8 012012 Hose, 1 1/4” 150# Black Rubber
9 012412 Hose, 1 1/2” 150# EPDM, L81
10 3316-0002 Valve, Relief Valve Dia Pump 1
11 600432 Hose, 2” Kanaflex 390 SD
12 BH-038-125-2 Bolt, 3/8” x 1 1/4” Gr. 2 6
13 LN-038-NI Locknut, 3/8” Nylon Insert 6
14 LS200-50 Strainer, 2” w/50 Mesh Screen 1
15 9910-D230 Pump, Diaphragm 63 GPM, 2 x 1 1/2 1
16 TEE 125 Tee, Poly, 1 1/4” Female 2
17 HB-200-90 Hose Barb Ell., 2” MPT x HBEL 4
18 HB-200 Hose Barb, 2” MPT x HB 4
19 2000-6 Rinse Nozzle, Tank Rinse 2
20 3371-0028 Jet Agitator, High Capacity 2
21 HB-125-150 Hose Barb, 1 1/4” MPT x 1 1/2” HB 1
22 HB-125 Hose Barb, 1 1/4” MPT x HB 3
23 HB-125-100 Hose Barb, 1 1/4” MPT x 1” HB 1
24 HB-125-100-90 Hose Barb Ell., 1 1/4” MPT x 1”HBEL 1
25 3T200G Tee, Hose Barb 2” Poly 3
26 HBT100 Hose Barb Tee, 1” HB x HB x HB 2
27 TEE 100 Tee, Poly, 1” Female 1
28 HB-100 Hose Barb, 1” MPT x HB 3
29 HB-075-100-90 Hose Barb Ell., 3/4” MPT x 1”HBEL 4
30 RN100-075 Reducer Nipple, 1” MPT x 3/4” NPT 2
31 HB-100-90 Hose Barb Ell., 1” MPT x HB EL 4
32 200CAP Coupling, 2” Female CAM Lever 2
33 200F Coupling, 2” Male ADPT/MPT 1
Item# Part # Description Quantity
Description: Plumbing using the Hydraulically Driven Diaphragm Pump
36
Section F
