680 High Clearance Sprayer - Parts & Schematics
Section F
34 V-204FP Valve, 2” 4 Bolted Ball Valve 1
35 V-200 Valve, 2” Bolted Ball Valve 1
36 MV100CF Valve, 1” Flanged Valve 2
37 M100G Gasket, For 1” Flanged 4
38 M100BRB90 Hose Barb, 1” Flanged Valve 4
39 FC100BJ Clamp, FOr 1” Flanged 4
40 BF200 Bulk Head, 2” Blind Hole Bolted 1
41 VSF-200 Valve Stub, 2”M ADPT x 2” F NPT 1
42 CPLG200 Coupling, 2” Poly Pipe 1
43 504-019 Check Valve, 2” 1
44 NW60401 Bulkhead Fitting 3/4” 2
45 NW60427 Bulkhead Fitting 1” 3
46 RB100-075 Reducer Bushing, 1” x 3/4” Poly 2
47 V-075 Valve, 3/4” Bolted Ball Valve 1
48 NW60405 Bulkhead Fitting 2” 1
49 200G Gasket, 2” Full Port Flanged 4
50 FC220 Clamp, 2” Full Port 4
51 M220TEE Tee, 2” Full Port 1
52 M220BRB 2” Full Port Flange x 2” Hose Barb 2
53 TBC150 Clamp, T-Bolt, 1 1/2” 3
54 NW60401 Bulkhead Fitting; 3/4" 1
55 PLUG 075 Plug; 3/4" MPT, Poly 1
Item# Part # Description Quantity
Description: Plumbing using the Hydraulically Driven Diaphragm Pump
37
Section F
