680 High Clearance Sprayer - Parts & Schematics
Section F
Description: Eductor Kit Assembly (Optional)
40
Section F
15 FW-031 Flatwasher, 5/16 14
16 HB-075-100-90 Hose Barb Ell, 3/4MPT x 1 HB ELL 3
17 HB-125 Hose Barb, 1 1/4” MPT x HB, Poly 1
18 HB-125-90 Hose Barb Ell., 1 1/4 MPT x HB ELL 1
19 HBT100 Hose Barb Tee, 1” HB x HB x HB 1
20 LN-025-NI Locknut, 1/4” Nylon Insert 4
21 LN-031-NI Locknut, 5/16” Nylon Insert 4
22 LW-031 Lockwasher, 5/166
23 NIP125-SH Nipple, 1 1/4 x Short, MPT 2
24 NIP200-SH Nipple, 2” x Short, MPT 1
25 MM3410 Reducer Nipple, 1 x 3/4 1
26 RN125-075 Reducer Nipple, 1 1/4 x 3/4 1
27 SL200-90 St Ell, 2” MPT x 2” FPT 1
28 TEE 125 Tee, Poly, 1 1/4” Female 1
29 TEE 200 Tee, Poly, 2” Female 1
30 UV075FP Valve, 3/4” Union Valve 1
31 V-075 Valve, 3/4” Bolted Ball Valve 1
32 V-125FP Valve, 1 1/4” Bolted Ball 1
33 VSTM-200 Valve, Stub 2”M NPT x 2” F NPT 1
34 M200TEEV100 Manifold Tee w/1” Inductor 1
35 M200MPT 2” Manifold x 2” Male Thread 1
36 M200125MPT 2” Flange x 1 1/4” Male Thread 1
37 M200BRB 2” Flange x 2” Hose Barb 1
38 FC200BJ 2” Worm Screw Clamp 3
39 150G 2” EPDM Gasket 3
40 600432 Hose, 2” Kanaflex 390 SD
41 504-010 Check Valve, 1 1/4” MPT 1
42 354010 Cover w/6” Vent 1
43 NW60401 Bulkhead Fitting 3/4” 1
44 200G Gasket, 2” Full Port Flanged 2
45 FC220 Clamp, 2” Full Port 2
46 M220TEE 2” Full Port Tee, Flanged 1
47 M220BRB 2” Full Port Flanged x 2” Hose Barb 2
Item# Part # Description Quantity
