680 High Clearance Sprayer - Parts & Schematics
Section F
Description: Hydraulic Switch Box Breakdown
1 782-1051 Fuse; 10 AMP AGC10 1
2 115-0171-211 Console Cable 1
3 46215 Fuse; 15 AMP, Spade Auto 1
4 063-0172-036 Switch Box Back 1
5 106-0159-438 Mounting Knob 2
6 107-0171-314 Mounting Bracket, Raven® Controller 2
008098 Mounting Bracket, TeeJet® Controller 1
7 412-2011-069 Switch w/Nut 1
8 412-2011-039 Switch w/Nut 7
9 107-0159-528 Switch Spacer 4
10 018-0159-409 Modified Cover 1
11 313-3000-031 Lock Washer 8
12 305-5000-086 Standoff; 6-32 x 1/4” M/F 2
13 063-0172-136 Face Plate Assembly 1
14 040-0159-566 Decal; Switch/Function 1
15 107-0172-270 Bottom Plate 1
16 Screw; 6-32 x 2 1/2” 2
17 Nut; 6-32 2
18 Lock Washer; 6-32 4
19 Nylon Washer; 6-32 2
20 Flat Washer; 6-32 2
21 Screw; 4-40 x 5/16” 6
22 BH-025-100-2 Bolt; 1/4" x 1" Hex. Gr. 2 2
23 LN-025-NI Lock Nut: 1/4" Nylon Insert 2
24 004776 Decal; Danger, Electrical Lines 1
