Mosaic fieldbus modules
8540801 • 01/02/2017 • Rev.15 14
No power
Connection with IO controller not present
Established connection with IO controller
IO controller in RUN state
Established connection with IO Controller
IO Controller in STOP state
No power or Module in SETUP or NW_INIT state
Module has shifted from the NW_INIT state
Diagnostic event (s) present
GREEN blinking (2 flashes)
Used to identify the network node
Module in EXCEPTION state
IP address not configured
Station name not configured
Module has encountered a major internal error
No power or no IP address
Module is in Process Active or Idle state
Duplicate IP address, or FATAL event
Major fault;
module in state EXCEPTION (or fatal event)
Minor fault in diagnostic object
IP conflict
