18 | Grandview® G800EC Gas Fireplace
installation
Clearance / Framing and Venting Configurations
The G800EC is designed to allow for unique installation options—depending on the desired finish.
Please review the options and follow the specific clearance, framing, and finishing options for that application.
The applications are as follows:
Cool Wall application: combustible materials can be installed right up to the fireplace opening with this option.
Clean Front application: non-combustible required when installing materials right to the fireplace opening with this option.
Outside Finish application: non-combustible materials required and the unit is finished to the edge of the fireplace or with either a finishing trim or faceplate..
See descriptive diagrams on the next page.
Clean Front + Outside Finish .................................................18
Cool Wall installation Part 1: Cool Wall conversion ...............19
Cool Wall Clearances ............................................................20
Cool Wall Mantel Clearances ...............................................21
Cool Wall Mantel Leg Clearances .........................................22
Cool Wall Application—Framing ............................................23
Chase Vent Installation ..........................................................24
Clean Front Installation—Clearances ....................................25
Clean Front Installation Mantel Clearances ...........................26
Clean Front Installation—Mantel Leg Clearances .................27
Non-Combustible Requirements: ...........................................27
Clean Front Installation—Framing (non Cool Wall) ................28
Clean Front Finishing.............................................................29
Optional Clean Front Trim Install Instructions: .......................29
Outside Finish Installation—Clearances ................................30
Outside Finish Installation—Mantel Clearances ....................31
Outside Finish Installation—Mantel Leg Clearances .............31
Outside Finish Installation—Clearances ................................32
Outside Finish—Finishing .....................................................33
Outside Finish—Faceplate Install ..........................................34
Outside Finish—Finishing Trim Install....................................36
Unit Assembly Prior to Installation .........................................38
Nailing Flange Installation:.....................................................38
