Grandview® G800EC Gas Fireplace | 83
parts list
Main Assembly
Part Description
1 761-574/P Valve Assembly - NG
1 761-576/P Valve Assembly - LP
2 911-188 Valve NG 885 SIT IPI 0.885.009
2 911-085 Valve LP 885 SIT IPI 0.885.002
3 911-276 Pilot Assembly IPI NG 2 Flame
3 911-277 Pilot Assembly IPI LP 2 Flame
3 910-036 Orifice SIT Pilot - NG #51 977.165
3 910-037 Orifice SIT Pilot - LP #30 977.167
4 911-190 Stepper Motor/Modulator - NG 0.907.023
4 911-011 Stepper Motor/Modulator - LP 0.907.012
N/S 904-996 Burner Orifice #42 - NG (PO512)
N/S 904-947 Burner Orifice #53 - LP (PO512)
5 911-037 Flame Sensor 0.915.905
6 911-038 Flame Electrode 0.915.020
7 910-432 NovaSit Pilot Tubing With Nuts
8 911-039 Two Way Pilot Hood
9 911-137 Pilot Hood Clip
N/S 908-528 Label Propane Red
N/S 908-529 Label Natural Gas Yellow
N/S 904-529 Allen Key 5/32 Long
N/S 904-165 Fitting 3/8 Male Flarex Mpt Strt Adaptor
N/S 905-038 Bracket Dormont Orifice Mnt 10-BZ001-9
N/S 656-039 Gasket Orifice Mount CB/CV40E
N/S 905-037 Gas Line SS Steel 3/8" ODX 12 inch
N/S 911-173 Wire Harness IFC No CPI Switch 584.924
N/S 911-177 Wire 4 Pos IFC Fan & Light
N/S 911-181 Wire Harness Battery Box Proflame II
N/S 911-193 Connector W/Jumper
N/S 911-241/P IFC Board SIT ProFlame II PV 0.584.305
N/S 911-210 External Antenna
N/S 911-292 Remote Control GTMFLSA SIT 0.584.040
N/S 911-289 Power Harness With Aux Connector
10 911-295 Light Assembly Top(Housing/Wires Assy/
Bulb Socket/Light Bulb)
11 911-296 Light Assembly Bottom (Housing/Wires Assy/
Bulb Socket/Light Bulb)
N/S 910-429 Receptacle Box Duplex Metal
12 761-053F Electrical Box Mounting Plate
N/S 910-369 Receptacle Box Low Volt. SC100A
N/S 910-576 Cover Wall Mount White GTM SIT 0.584.803
N/S 910-428 Receptacle Duplex White
N/S 910-430 Receptacle Cover Duplex Metal
N/S 904-687 Connector Clamp 3/8 CI-804
N/S 911-187 Remote Receiver/Battery Holder 584.103
Paart Description
N/S 918-835 Decal Logo Regency / Flame Sit Remote
N/S 918-876 Decal Remote Quick Reference GTMF
N/S 948-099 Spring Compression 3 inch Long Zinc Plated
LC 085J 10 M
N/S 396-179 Gasket Bulk Hd (Side Firebox Pilot Line)
N/S 396-178F Plate Bulk Head Clamp
13 761-525 Burner Assembly NG/LP c/w Cap G800
14 761-040 Door Frame Only
15 940-506/P Replacement Glass (Includes Gasket)
(Size : 27 1/2" H x 31 7/8" W)
16 936-157 Gasket Tadpole Tape (Sold Per foot)
N/S 936-220 Gasket Tape 2" Wide Graphite
N/S 904-691 Clip-U
N/S 761-038/P Mesh Glass Guard
N/S 366-049 Neocermaic Glass (Lights) Size : 1 5/8"
x 1 1/4")
N/S 761-505 Bottom Door Latch Assembly (Each)
N/S 761-506 Top Door Latch Assembly (Each)
N/S 761-514 Log Support Brackets (Set of 2)
N/S 911-297 Halogen Bulb G9/120V/18W (Each)
To Next Page
