Regency G800EC - Light Bulb Replacement-Bottom Lights + Top Light

Grandview® G800EC Gas Fireplace | 79
maintenance
Light bulb replacement—Bottom Lights
Light bulb replacement—Top Light
1. Remove screen, glass door, logs and any other media, log grate, and lower
panel (if installed).
2. Remove two (2) screws from light assembly cover in the locations shown
below.
3. Lift up and slide light assembly cover forward to remove.
4. Install or replace bulbs as required.
NOTE: Do not touch bulbs with bare hands, use gloves or a tissue when
handling bulbs.
5. Reverse steps to reassemble unit.
1. Turn o replace and wait until it has reached room temperature.
2. Remove the Screen Barrier. See Section: Safety screen removal / Installation.
3. Remove the glass door: See Section: Glass door removal / Installation.
4. Remove the two screws with a phillips-head screwdriver as shown below.
5. Remove the Top Light Casing by lifting up and out.
6. Remove the old light bulb by pulling out of the socket.
7. Install the new bulb using solf, clean, gloves. Do NOT touch the bulb with your
bare hands.
8. Reverse steps to re-install. NOTE: Be careful not to pinch the wiring when
re-installing the Top Light Casing. There is a cut-out for the wiring to route
through.
