Grandview® G800EC Gas Fireplace | 35
installation
3
4
"
Nailing Flange
Tabs folded
forward
Mounting Tabs
folded forward
Mounting
Tab Folded
forward
Nailing Flange
folded forward
Framing
Face Plate
Top View
Install the Face Plate by resting the arms on the
Face Plate on top of the mounting tabs.
Adjust le and right to center the Face Plate.
NOTE: Do not to touch the Face Plate without
clean, so, gloves. Dirt or oils can be transferred
onto the nish and become permanent.
Critical Finishing Gap
Faceplate - Finishing:
A 1/2” gap must be maintained on the sides of the
replace to allow the Face Plate to be installed and
removed.
Do NOT nish past the front face of the replace.
