Why is Rem GrainVac VR12 GrainVac surging or pulsing?
The GrainVac surges or pulses because it could be starved for air. Increase the air supply to allow enough air for a smooth flow of grain. Another cause could be a plugged hose, so remove any obstructions. Check the end dump double doors to ensure they close completely and securely, and adjust or replace the spring tension if necessary.
What causes excessive material to come out of the exhaust of Rem GrainVac VR12 Construction Equipment?
An excessive amount of material coming out of the exhaust could be due to several reasons. The drum screen might be damaged, allowing material to pass through. Alternatively, the cast aluminum inlet on the drum/rotor inlet could be damaged or missing, also allowing material to bypass the screen. A damaged rear rotating drum screen bearing could cause premature wear of the cast aluminum inlet. Lastly, if the grain size is smaller than the screen's hole size, adjust the air throttle.
What causes suction problems with Rem GrainVac VR12?
Suction problems can occur if the drum is plugged, so remove the inspection door and clean the drum screen with a steel brush or compressed air. Plugged hoses can also cause issues; locate and remove any obstructions. Other causes include a damaged drum/rotor inlet, which requires replacing the cast aluminum inlet, or a damaged lining in the steel flex tube, which needs repair or replacement. Lastly, ensure the body inspection door and auger clean-out door are fully closed to prevent air leaks.
What to do if no material comes out of the end dump double doors and auger of Rem GrainVac VR12?
If no material is coming out of the end dump double doors and the end of the auger, it could be that the end dump double doors are not sealing properly, causing air to be sucked back down the auger tube. Ensure the doors open and close freely, and adjust the tension on the spring. Loose or slipping belts or a damaged chain can also be the cause; tighten or replace the belts, and replace any damaged or worn chain. Additionally, the auger might not be turning due to misalignment of the drive dogs; realign the drive dog(s).
Why is Rem Construction Equipment causing grain damage?
Grain damage can occur for a few reasons. A new machine may need a short break-in period of approximately 5-10 hours for the hard-surfaced augers to become smooth. If the airlock spring tension is too tight, it can also cause damage, so loosen the airlock, though this may diminish capacity. Inherent sensitivity of the grain type or condition can also be a factor, in which case you can try operating at a lower PTO rpm.
What to do if the augers fold extremely slow or the top section will not fold out on Rem GrainVac VR12?
If the augers fold extremely slowly or the top section won't fold out, a small foreign object might be obstructing an orifice in the hydraulic system. Ensure hoses are properly pushed into the tractor, check for damaged hose tips and tractor couplers, and clean out any objects lodged in orifice restrictions in hydraulic fittings at the male tips, lower lift cylinder, and control valve. Also, check the tractor flow controls.
What to do if Rem GrainVac VR12 Construction Equipment has suction problems?
If your Rem Construction Equipment is experiencing suction problems, there could be several causes. First, check all joints in the suction tubes for leaks and readjust or replace any damaged clamps. Ensure the tractor is operating at the correct PTO speed, ideally 1000 rpm, by using a handheld digital tachometer. Verify the steel flex hose is connected correctly, with the arrow indicating the proper airflow direction. Also, inspect and clean the end dumper doors, ensuring they close securely, and adjust or replace the tension spring if needed. Review the operating instructions in Chapter 4 to confirm you're using the correct vacuuming technique. Finally, check for damaged foam rubber seals in the auger joints and replace them if necessary, and ensure belts/chains are correctly aligned and ...
What to do if Rem Construction Equipment is plugging and damaging belts?
If your GrainVac is plugging and damaging belts, it could be due to light grain being vacuumed into the body chamber, causing the rotary drum screen to stop. Refer to Section 4.8 for air throttle adjustment instructions. Another cause might be a foreign object lodged in the auger, which requires cleaning out the GrainVac body, removing the object, and replacing the shear pin. Also, a broken gearbox drive chain can cause this issue, requiring you to clean out the GrainVac body, inspect the auger, and replace the chain, oiling it afterward. Bent auger flighting impeding grain flow or damaged foam rubber seals in the auger joints can also contribute, so inspect and repair/replace the flighting or seals as needed. If the shear pin breaks repeatedly due to a malfunctioning gearbox, remove the c...
Defines the primary function, intended applications, and operational boundaries of the GrainVac.
Identifies and illustrates the major components and their functions within the GrainVac.
Explains safety symbols, signal words, general responsibilities, and required equipment.
Details essential personal protective equipment (PPE) needed for safe operation.
Covers work area, power drives, lockout, rotating parts, flighting, tires, and overhead power lines safety.
Explains the importance, location, and proper installation of safety decals.
Provides critical safety guidelines for moving the GrainVac to different locations.
Details the steps for securely attaching and transporting the GrainVac with a tractor or truck.
Outlines essential safety practices to follow during GrainVac operation.
Lists critical checks to perform before operating the GrainVac for safety and performance.
Details lockout steps and initial machine break-in procedures.
Specifies tractor requirements and guides positioning and setup at the work site.
Explains jack stabilization, auger lift, and tachometer/hour meter functions.
Provides a step-by-step guide for operating the GrainVac for material vacuuming.
Offers tips on hose use, characteristics, and the "9 S's" for maximizing performance.
Outlines the steps for safely shutting down the GrainVac after use, including emergency shutdown.
Outlines safety precautions and requirements for performing maintenance.
Provides a table detailing maintenance tasks at specified intervals.
Lists the types and capacities of fluids and lubricants required for the equipment.
Details step-by-step instructions for various maintenance tasks.
Covers shear bolts, PTO, belts, chains, sprockets, and idler pulley maintenance.
Details maintenance for end dump doors, rotors, wear wraps, and bearing cartridges.
Provides instructions for gearbox removal, oil checking, and breather cleaning.
Outlines safety precautions and requirements for performing service tasks.
Details procedures for flighting removal/replacement and split taper bushing service.
Covers rotor and bearing cartridge removal, inspection, and wear wrap replacement.
Provides instructions for drum removal, cleaning, and maintenance.
Outlines safety precautions and steps for placing the GrainVac into storage.
Provides instructions for preparing the GrainVac for use after a storage period.
Addresses problems with vacuum suction, grain flow, and overall performance.
Covers issues with augers, belts, chains, shear pins, and gearbox engagement.
Discusses problems with material output, exhaust, and grain damage.
Lists the technical specifications for the GrainVac VR12 model.
Provides torque specifications for various SAE and metric bolts.
Details the EC Declaration of Conformity and applicable standards.
General| Brand | Rem |
|---|---|
| Model | GrainVac VR12 |
| Category | Construction Equipment |
| Language | English |
