1.3. Components Overview
Throughout this manual, names are referred to of various components which together
make up the GrainVac VR12 and are identified in Figure 1.2.
Figure 1.2 Overview of Major Components of GrainVac VR12
Operator Orientation: The directions left, right, front, and rear, as mentioned
throughout the manual, are as seen from the tractor driver seat and facing in the
direction of travel when the equipment is being transported.
TELESCOPING INLET
END DUMP
SPOUT
UNLOADING
AUGER
AIR
OUTLET
FLOOR
SWEEP
HOSES & TUBES
NOZZLES
HITCH
VAC
BODY
BODY
INLET
PTO
