11
Fig. 04 Dimensions Selecta combi
04.W5H.79.00001
Ê Return connection 22 mm Ø o/d
É Flow connection 22 mm Ø o/d
Ï Gas connection 15 mm Ø o/d
Ð Combustion air supply connection 100 mm Ø i/d
Ñ Flue gas discharge connection 60 mm Ø i/d
Ó DHW inlet connection 15 mm Ø o/d
Ô DHW outlet connection 15 mm Ø o/d
Ò Condensate connection 25 mm Ø
Ù Safety valve discharge 15 mm Ø
