11.2.5 Checking and cleaning the inspection glass
Fig. 26 Checking and cleaning the inspection glass
pdf
- Isolate the electrical supply to the boiler.
- Remove the boiler front casing cover.
- Remove the two screws holding the inspection glass plate.
- Replace inspection glass assembly, replacing the gasket if it was damaged during
removal.
- Re-fit front casing cover replacing the gasket if it was damaged during removal.
