Remeha Selecta
20
Ø D (mm)
Ø 60/100
Max. length horizontal including bend ‘L’
Max. length vertical with no bends ‘L’
m
m
7*
9*
Deduct per extra bend 90° m 2
Deduct per extra bend 45° m 1
Table 03 Permissible flue gas discharge lengths with closed systems
* Note: For lengths in excess of this, the 80/125 system can be used with a suitable
adaptor. Please contact Broag for the required details.
Fig. 11 Remeha Selecta with concentric horizontal flue
04.W5H.79.00011
