REMEHA Selecta - Page 63

63
Pos.
nr.
Part description Additional detail
1 Casing front panel
2 Cover grey plastic c/w logo and retaining star washers
3
Screw self tapper Phillips
4,2 mm x 19 mm
for front casing x 2
4 Casing side panel left or right hand/ universal
5 Casing rear and top panel assembly
6 Flue connection pipe 70/60 mm Ø
7 Sealing ring Flue connection 60 mm Ø
8 Grommet 100 mm i/d flue pipe to top casing
9 Expansion vessel 8,0 Litre
10 Heat exchanger
11 Sealing ring 70 mm Ø flue to heat exchanger
12
Sensor temperature Elmwood
NTC 12K/007
flow and return
13 Burner
14 Gasket for burner to front plate
15 Screw M4 x 10 for burner to front plate x 3
16 Insulation for front plate
17 Sealing profile for front plate to heat exchanger
18 Front plate for heat exchanger
19 Gasket for electrode
20 Electrode ignition/ionisation MX REBA incl. gasket and 2 screws
21 Grommet for electrode cap
22
Cable ignition/ionisation c/w cap and
grommet
23 Mounting frame for Inspection glass
24 Glass inspection 32 x 32 x 3 mm c/w gasket and 2 screws
25 Gasket for inspection glass
26 Nut M5 for venturi to fan and front plate x 4
27 Gasket venturi to front plate
28 Gasket fan to venturi
29
Restriction cone Natural Gas
Restriction cone kit for LPG
30
Gasket
23.8 mm o/d x 17.2 mm I/d x 2 mm
for gas valve x 2
31 Pipe assembly gas for gas valve to venturi
32
Fan assembly
EBM G1G 126 AC 13-13
33
Hose silicone
4 mm i/d-8 mm (per M)
for gas valve to venturi and air vent
discharge
34 Valve gas multi block SIT 848 24V ¾"
35 Cover MCBA control board
36
Screws self tapper phillips
35 mm x 7 mm
for MCBA cover x 2
37 Control board MCBA1495D S
