65
38 Sealing profile MCBA to instrument panel
39 Pressure gauge c/w capilliary
40 Dust cap for PC/PDA connection
41 Instrument panel only (no fittings)
42 Pipe gas connection 15 mm o/d for supply to gas valve
43
Air inlet assembly c/w damper, valve
and seal ring
44 Screw pan head phillips M4 x 12 mm for air inlet assy to fan x 3
45 Syphon reservoir cup only
46 Siphon assembly complete
47 Pipe assembly flow heat X to system 22mm o/d
51 Pipe assembly return pump to heat X to expansion vessel
52 Valve safety pressure relief ½" set to 3 bar
53 Pocket assembly for pressure gauge connection
54 Vent auto air bleed device 3/8"
55 Valve Non Return 3/8" for auto air vent
56 Gasket 30 mm o/d x 12 i/d x 3 mm pump union x 2
57 Pump Grundfos UPR15/50 1"
58 Elbow ½" / 15 mm safety valve to discharge pipe
59 Pipe s/v discharge 15 mm safety valve to discharge outlet
60 Pipe return 22 mm system to pump
68 Cable set fan to wiring harness
69 Casing bottom plate (System)
70 Grommet 46 mm o/d x 22 mm I/d black condensate pipe to bottom casing
71 Grommet 22 mm Ø red flow pipe to bottom casing
72 Venturi assembly
73 Clip raymond 12267 for 4,2 mm Ø front cover screw x 2
74 Transformer CKZ050122517 (24 v)
75 Grommet 15 mm Ø yellow gas pipe to bottom casing
78 Grommet 15 mm Ø black
s/v discharge pipe
to bottom casing
79 Grommet 22 mm Ø blue return pipe to bottom casing
80 Nut M6 for front plate to heat exchanger x 9
81 Cable gland APG 11x 6 - 9 FS mains cable entry
82 Grommet Ø 20 mm black cable entry
83 O ring 65 mm Ø x 3 mm air inlet to fan
84 Bolt M5 x 16 mm fan to venturi x 2
86
Star washers
(for retaining grey plastic cover)
for retaining grey plastic cover x 3
87 Bolt M6x16mm for inspection glass mounting frame
88
Washer spring ring
4mm o/d x 3mm I/d
for Ign electrode
mtg screws x 2
89 Grommet 30 mm Ø black blind
- Cover plate - not illustrated for pipework connections
-
Cable complete wiring harness - not
illustrated
not illustrated
Cable mains supply - not illustrated
230v - 3core flex
c/w cable gland
Table 14 Part list Selecta system boiler
