Remlinger 2300 - Parts Identification; Pull Type Hitch Parts

35 MAN-GD-2300-002
Pull Type Hitch Parts
Ref. # Description Qt
y
.Part #
1 Hitch Weldment 1 RM-RR1483
2 Front Linka
g
e Bar 2 RM-RR1478
3 Rear Linka
g
e Bar 2 RM-RR1479
4 3/8”-16 x 1 1/2” HCS 2
5 3/8” Lock Washer 4
6 3/8”-16 Hex Nu
t
4
7 Linka
g
e Spacer 2 RM-RR1484
8 3/8”-16 x 2 1/2" HCS 2
9 1”-8 x 3 1/2” HCS 2
10 1”-8 Top Lock Nu
t
3
11 Safet
y
Chain 1 RM-J1799
12 1”-8 x 7” HCS 1
13 Jack Assembl
y
W/ Brackets 1 RM-J8205
14 Clamp, H
y
draulic Hose
(
2
)
2 RM-R121848
15 3/8”-16 Hex Lock Nu
t
2
16 C
y
linder Stop 1 RM-S16840
17 Bushin
g
, 2" Cat III 2 RM-M 3317
18 1 1/8” Machine Washer - 14 Ga.. 2
19 3/8" x 2-1/2" Roll Pin 1 RM-J1513
20 7/16” L
y
nch Pin 1 RM-J15481
21 Upper 3 Pt. Pin, Cat II 1 RM-S18456
22 Bushin
g
, 1-3/8 x 1-1/8 x 1/2 2 RM-J00849
23 Bushin
g
, 1-3/8 x 1-1/8 x 3/4 2 RM-J00843
