Remlinger 2300 - Small Seed Meter Assembly

54 MAN-GD-2300-002
Small Seed Meter Assembly
Ref # Description Qt
y
Part #
1 Swivel Bamlet 1 RM-R820015
2 Seed Meter, GS, Housin
g
, Roller, Bushin
g
1 RM-R522458
3 1/4”-20 x 1/4” Socket Head Setscrew 2
4 3/16” Flat Washer 2
5 3/16” x 2 1/2” Bolt 1
3/16” Hex Lock Nu
t
1
7 Hose Clamp, 5/8-1”, #5 1 RM-J23192
8 Shaft, Collar, 1/2” 2 RM-M3709
